Basic concepts

Martijn Wieling
University of Groningen

This lecture

  • Descriptive vs. inferential statistics
  • Sample vs. population
  • (Types of) variables
  • Distribution of a variable: central tendency and variation
  • Standardized scores
  • Checking for a normal distribution
  • Reasoning about the population using a sample
    • Relation between population (mean) and sample (mean)
    • Confidence interval for population mean based on sample mean
    • Testing a hypothesis about the population using a sample
    • Statistical significance
    • Error types

Question 1

Why use statistics?

  • Why use statistics?
    • Summarize data (descriptive statistics)
    • Assess relationships in data (inferential statistics)

Descriptive vs. inferential statistics

  • Descriptive statistics:
    • Statistics used to describe (sample) data without further conclusions
      • Measures of central tendency: Mean, median, mode
      • Measures of variation (or spread): range, IQR, variance, standard deviation
  • Inferential statistics:
    • Describe data of sample in order to infer patterns in the population
      • Statistical tests: \(t\)-test, \(\chi^2\)-test, etc.

Sample vs. population

Why study a sample?

  • Studying the whole population is (frequently) practically impossible
  • Sample is a (selected) subset of population and thus more accessible
    • Selection of representative sample is very important!

Question 2

Types of variables

Question 3

Characterizing nominal variables

plot of chunk unnamed-chunk-1

Characterizing numerical variables: distribution

  • We are generally not interested in individual values of a variable, but rather all values and their frequency
  • This is captured by a distribution
    • Famous distribution: Normal distribution ("bell-shaped" curve): e.g., IQ scores

plot of chunk unnamed-chunk-2

Interpreting a density curve

plot of chunk unnamed-chunk-3

  • The total area under a density curve is equal to 1
  • A density curve does not provide information about the frequency of one value
    • E.g., there might be no one who has a value of exactly 6.1
  • It only provides information about an interval
    • E.g., more than 50% of the values lie between 5.5 and 7.5

Interpreting a density curve: normal distribution

plot of chunk unnamed-chunk-4

  • The normal distribution has convenient characteristics
    • Completely symmetric
    • Red area: (about) 68%
    • Red and green area: (about) 95%

Characterizing the distribution of numerical variables

  • A distribution can also be characterized by measures of center and variation
    • (skewness measures the symmetry of the distribution; not covered further)

Characterizing numerical variables: central tendency

  • Mode: most frequent element (for nominal data: only meaningful measure)
  • Median: when data is sorted from small to large, it is the middle value
  • Mean: arithmetical average

\[\bar{x} = \frac{x_1 + x_2 + \cdots + x_n}{n} = \frac{1}{n}\sum\limits_{i=1}^n x_i\]

Question 4

Measure of variation: quantiles

  • Quantiles: cutpoints to divide the sorted data in subsets of equal size
    • Quartiles: three cutpoints to divide the data in four equal-sized sets
      • \(q_1\) (1st quartile): cutpoint between 1st and 2nd group
      • \(q_2\) (2nd quartile): cutpoint between 2nd and 3rd group (= median!)
      • \(q_3\) (3rd quartile): cutpoint between 3rd and 4th group
    • Percentiles: divide data in hundred equal-sized subsets
      • \(q_1\) = 25th percentile
      • \(q_2\) (= median) = 50th percentile
      • Score at $n$th percentile is better than \(n\)% of scores

Measure of variation: range

  • Minimum, maximum: lowest and highest value
  • Range: difference between minimum and maximum
  • Interquartile range (IQR): \(q_3\) - \(q_1\)

Visualizing variation: box plot (box-and-whisker plot)

  • A box plot is used to visualize variation of a variable
    • Box (IQR): \(q_1\) (bottom), median (thickest line), \(q_3\) (top)
      • (In example below, \(q_1\) and median have the same value)
    • Whiskers: maximum (top) and minimum (bottom) non-outlier value
    • Circle(s): outliers (> 1.5 IQR distance from box) plot of chunk unnamed-chunk-5

Important measure of variation: variance

  • Deviation: difference between mean and individual value
  • Variance: average squared deviation
    • Squared in order to make negative differences positive
    • Population variance: \[\sigma^2 = \frac{1}{n}\sum\limits_{i=1}^n (x_i - \mu)^2\]
    • As sample mean (\(\bar{x}\) or \(m\)) is approximation of population mean (\(\mu\)), sample variance formula contains division by \(n-1\) (results in slightly higher variance): \[s^2 = \frac{1}{n-1}\sum\limits_{i=1}^n (x_i - \bar{x})^2\]

Important measure of variation: standard deviation

  • Standard deviation is square root of variance \[\sigma = \sqrt{\sigma^2} = \sqrt{\frac{1}{n}\sum\limits_{i=1}^n (x_i - \mu)^2}\] \[s = \sqrt{s^2} = \sqrt{\frac{1}{n-1}\sum\limits_{i=1}^n (x_i - \bar{x})^2}\]

Question 5

Normal distribution and standard deviation (1)

plot of chunk unnamed-chunk-6

\(P(\mu - \sigma \leq x \leq \mu + \sigma) \approx 68\%\)     (34 + 34)
\(P(\mu - 2\sigma \leq x \leq \mu + 2\sigma) \approx 95\%\)     (34 + 34 + 13.5 + 13.5)
\(P(\mu - 3\sigma \leq x \leq \mu + 3\sigma) \approx 99.7\%\)     (34 + 34 + 13.5 + 13.5 + 2.35 + 2.35)

Normal distribution and standard deviation (2)

plot of chunk unnamed-chunk-7

\(P(85 \leq \rm{IQ} \leq 115) \approx 68\%\)     (34 + 34)
\(P(70 \leq \rm{IQ} \leq 130) \approx 95\%\)     (34 + 34 + 13.5 + 13.5)
\(P(55 \leq \rm{IQ} \leq 145) \approx 99.7\%\)     (34 + 34 + 13.5 + 13.5 + 2.35 + 2.35)

  • IQ scores are normally distributed with mean 100 and standard deviation 15

Standardized scores

  • Standardization helps facilitate interpretation
  • E.g., how to interpret: "Emma got a score of 112" and "Tom got a score of 105"
  • Interpretation should be done with respect to mean \(\mu\) and standard deviation \(\sigma\)
    • Raw scores can be transformed to standardized scores (\(z\)-scores or \(z\)-values) \[z = \frac{x - \mu}{\sigma} = \frac{\rm{deviation}}{\rm{standard}\,\rm{deviation}}\]
    • Interpretation: difference of value from mean in number of standard deviations

Calculating standardized values

  • Suppose \(\mu = 108\), \(\sigma = 4\), then: \[z_{112} = \frac{x - \mu}{\sigma} = \frac{112 - 108}{4} = 1\] \[z_{105} = \frac{105 - 108}{4} = -0.75\]
  • \(z\) shows distance from mean in number of standard deviations

Question 6

Distribution of standardized variables

  • If we transform all raw scores of a variable into \(z\)-scores using: \[z = \frac{x - \mu}{\sigma} = \frac{\rm{deviation}}{\rm{standard}\,\rm{deviation}}\]
  • We obtain a new transformed variable whose
    • Mean is 0
    • Standard deviation is 1
  • In sum: \(z\)-score = distance from \(\mu\) in \(\sigma\)'s
  • \(z\)-scores are useful for interpretation and hypothesis testing

Standard normal distribution

plot of chunk unnamed-chunk-8

\(P(-1 \leq z \leq 1) \approx 68\%\)     (34 + 34)
\(P(-2 \leq z \leq 2) \approx 95\%\)     (34 + 34 + 13.5 + 13.5)
\(P(-3 \leq z \leq 3) \approx 99.7\%\)     (34 + 34 + 13.5 + 13.5 + 2.35 + 2.35)

Question 7

For comparison: normal distribution

plot of chunk unnamed-chunk-9

\(P(\mu - \sigma \leq x \leq \mu + \sigma) \approx 68\%\)     (34 + 34)
\(P(\mu - 2\sigma \leq x \leq \mu + 2\sigma) \approx 95\%\)     (34 + 34 + 13.5 + 13.5)
\(P(\mu - 3\sigma \leq x \leq \mu + 3\sigma) \approx 99.7\%\)     (34 + 34 + 13.5 + 13.5 + 2.35 + 2.35)

Checking normality assumption

  • Some statistical tests (e.g., \(t\)-test) require that the data is (roughly) normally distributed
  • How to test this?
    • Using visual inspection of a normal quantile plot (or: quantile-quantile plot)
      • A straight line in this graph indicates a (roughly) normal distribution
    • (Alternatively, you can use the Shapiro-Wilk test)

Normal quantile plot: how it works

  • Sort the data from smallest to largest to determine quantiles (e.g., percentiles)
    • E.g., median for 50th percentile
  • Calculate \(z\)-values belonging to the quantiles (e.g., percentiles) of a standard normal distribution
    • E.g., \(z =\) 0 for 50th percentile, \(z =\) 2 for 97.5th percentile, etc.
  • Plot data values (\(y\)-axis) against normal quantile values (\(x\)-axis)
    • If points on (or close to) straight line: values normally distributed

Normal quantile plot example

plot of chunk unnamed-chunk-10

Selecting a sample

  • Selecting a sample from a population includes an element of chance: which individuals are studied?
  • Important question: How to reason about the population using a sample?
    • Anwered using the Central Limit Theorem

Central Limit Theorem

  • Suppose we would gather many different samples from the population, then the distribution of the sample means will always be normally distributed
    • The mean of these sample means (\(\bar{x}\)) will be the population mean (\(m_{\bar{x}} = \mu\))
    • The standard deviation of the sample means (standard error SE) is dependent on the sample size \(n\) and the population standard deviation \(\sigma\) : SE \(= s_{\bar{x}} = \frac{\sigma}{\sqrt{n}}\)

plot of chunk unnamed-chunk-11

Reasoning about the population (1)

  • Given that the distribution of sample means is normally distributed \(N(\mu,\sigma/\sqrt{n})\), having one randomly selected sample allows us to reason about the population
  • Requirement: sample is representative (unbiased sample)
    • Random selection helps avoid bias

Reasoning about the population (2)

  • Given a representative sample:
    • We estimate the population mean as equal to the sample mean (best guess)
    • How certain we are of this estimate depends on the standard error: \(\sigma/\sqrt{n}\)
      • Increasing sample size \(n\) reduces uncertainty
        • Hard work pays off (in exactness), but it doesn't pay of quickly: \(\sqrt(n)\)
      • Sample means are normally distributed (CLT):
        • We can relate a sample mean to the population mean by using characteristics of the normal distribution

Question 8

Normal distribution

  • We know the probability of an element \(x\) having a value close to the mean \(\mu\):

plot of chunk unnamed-chunk-12

\(P(\mu - \sigma \leq x \leq \mu + \sigma) \approx 68\%\)     (34 + 34)
\(P(\mu - 2\sigma \leq x \leq \mu + 2\sigma) \approx 95\%\)     (34 + 34 + 13.5 + 13.5)
\(P(\mu - 3\sigma \leq x \leq \mu + 3\sigma) \approx 99.7\%\)     (34 + 34 + 13.5 + 13.5 + 2.35 + 2.35)

Normal distribution: \(z\)-scores

  • With standardized values: \(z = (x - \mu)/\sigma \Rightarrow \mu = 0\) and \(\sigma = 1\)

plot of chunk unnamed-chunk-13

\(P(-1 \leq z \leq 1) \approx 68\%\)     (34 + 34)
\(P(-2 \leq z \leq 2) \approx 95\%\)     (34 + 34 + 13.5 + 13.5)
\(P(-3 \leq z \leq 3) \approx 99.7\%\)     (34 + 34 + 13.5 + 13.5 + 2.35 + 2.35)

Reasoning about the population (3)

  • Sample means can be related to the population in two ways:
    • Using a confidence interval
      • An interval which is likely to contain the true population mean
    • Using a hypothesis test
      • Tests if hypothesis about population is compatible with sample result

Confidence interval

  • Definition: there is an \(x\)% probability that when computing an \(x\)% confidence interval on the basis of a sample, it contains \(\mu\)
    • Confidence interval gives estimate of plausible values for the population mean

Confidence interval: example (1)

  • Consider the following example:
    You want to know how many hours per week a student of the university spends speaking English. The standard deviation \(\sigma\) for the university is 1 hr/wk.
    • You collect data from 100 randomly chosen students
    • You calculate the sample mean \(m = 5\) hr/wk (N.B. in my notation: \(m\) = \(\bar{x}\))
    • You therefore estimate the population mean \(\mu = 5\) hr/wk and SE \(= 1/\sqrt{100} = 0.1\) hr/wk
  • What is the 95% confidence interval (CI) of the mean?

Confidence interval: example (2)

  • According to the CLT, the sample means are normally distributed

plot of chunk unnamed-chunk-14

  • 95% of the sample means lie within \(m \pm\) 2 SE
    • (i.e. actually it is \(m \pm\) 1.96 SE, but we round this to \(m \pm\) 2 SE)
  • With \(m\) = 5 and SE = 0.1, 95% CI is 5 \(\pm\) 2$\times$0.1 = (4.8 hr/wk, 5.2 hr/wk)

Question 9

Hypotheses

  • Instead of confidence intervals we often interpret samples as hypothesis tests about populations
  • Examples of hypotheses
    • Answering online lecture questions is related to the course grade
    • Women and men differ in their English proficiency
    • Nouns take longer to read than verbs

Hypothesis testing (1)

  • Testing these hypotheses requires empirical and variable data
    • Empirical: based on observation rather than theory alone
    • Variable: individual cases vary
  • Hypotheses can be derived from theory, but also from observations if theory is incomplete

Hypothesis testing (2)

  • We start from a research question:
    Is answering online lecture questions related to the course grade?
  • Which we then formulate as a hypothesis (i.e. a statement):
    Answering online lecture questions is related to the course grade
  • For statistics to be useful, this needs to be translated to a concrete form:
    Students answering online lecture questions score higher than those who do not

Hypothesis testing (3)

  • Students answering online lecture questions score higher than those who do not
  • What is meant by this?
    All students answering online lecture questions score higher than those who do not?
    • Probably not, the data is variable, there are other factors:
      • Attention level of each student
      • Difficulty of the lecture
      • If the questions were answered seriously
  • We need statistics to abstract away from the variability of the observations (i.e. unsystematic variation)

Hypothesis testing (4)

  • Students answering online lecture questions score higher than those who do not
  • Meaning:
    • Not: All students answering online lecture questions score higher than those who do not
    • But: On average, students answering online lecture questions score higher than those who do not

Testing a hypothesis using a sample (1)

  • On average, students answering online lecture questions score higher than those who do not
  • This hypothesis must be studied on the basis of a sample, i.e. a limited number of students following a course with online lecture questions
    • Of course we're interested in the population, i.e. all students who followed a course with online lecture questions

Testing a hypothesis using a sample (2)

  • The hypothesis concerns the population, but it is studied through a representative sample
    • Students answering online lecture questions score higher than those who do not
      (study based on 30 students who answered the questions and 30 who did not)
    • Women have higher English proficiency than men
      (study based on 40 men and 40 women)
    • Nouns take longer to read than verbs
      (studied on the basis of 35 people's reading of 100 nouns and verbs)

Question 10

Analysis: when is a difference real?

  • Given a testable hypothesis:
    Students answering online lecture questions score higher than those who do not
    • You collect the final course grade for 30 randomly selected students who answered the online questions and 30 who did not
  • Will any difference in average grade (in the right direction) be proof?
    • Probably not: very small differences might be due to chance (unsystematic variation)
  • Therefore we use statistics to analyze the results
    • Statistically significant results are those unlikely to be due to chance

Comparing a sample to population: \(z\)-test

  • \(z\)-test allows assessing difference between sample and population
    • \(\mu\) and \(\sigma\) for the population should be known (standardized tests: e.g., IQ test)
  • Sample mean \(m\) is compared to population mean \(\mu\)

Example of \(z\)-test

  • You think Computer Assisted Language Learning may be effective for kids
  • You give a standard test of language proficiency (\(\mu\) = 70, \(\sigma\) = 14) to 49 randomly chosen childen who followed a CALL program
    • You find \(m\) = 74
    • You calculate SE = \(\sigma/\sqrt{n} = 14/\sqrt{49} = 2\)
    • 74 is 2 SE above the population mean: at the 97.5th percentile

plot of chunk unnamed-chunk-15

Conclusions of \(z\)-test

  • Group with CALL scored 2 SE above mean (\(z\)-score of 2)
    • Chance of this (or more extreme result) is only 2.5%, so very unlikely that this is due to chance
  • Conclusion: CALL programs are probably helping
    • However, it is also possible that CALL is not helping, but the effect is caused by some other factor
      • Such as the sample including lots of proficient kids
      • This is a confounding factor: an influential hidden variable (a variable not used in a study)

Question 11

Importance of sample size

  • Suppose we would have used 9 children as opposed to 49, at what percentile would a sample mean of \(m\) = 74 be?
    • SE = \(\sigma/\sqrt{n} = 14/\sqrt{9} \approx 4.7\)
    • \(m\) = 74 is less than 1 SE above the mean, i.e. at less than the 84th percentile
      • Sample means of this value are found by chance more than 16% of the time (i.e. likely due to chance): not enough reason to suspect an effect of CALL

plot of chunk unnamed-chunk-16

Statistical reasoning: two hypotheses (1)

  • Rather than one hypothesis, we create two hypotheses about the data:
    • The null hypothesis (\(H_0\)) and the alternative hypothesis (\(H_a\))
    • The null hypothesis states that there is no relationship between two measured phenomena (e.g., CALL program and test score), while the alternative hypothesis states there is

Statistical reasoning: two hypotheses (2)

  • For the CALL example (49 children):
    • \(H_0\): \(\mu_{CALL} = 70\) (the population mean of people using CALL is 70)
    • \(H_a\): \(\mu_{CALL} > 70\) (the population mean of people using CALL is higher than 70)
    • While \(m\) = 74, suggests that \(H_a\) is right, this might be due to chance, so we would need enough evidence (i.e. low SE) to accept it over the null hypothesis
    • Logically, \(H_0\) is the inverse of \(H_a\), and we'd expect \(H_0\): \(\mu_{CALL} \leq 70\), but we usually see '\(=\)' in formulations

Statistical reasoning (1)

\(H_0\): \(\mu_{CALL} = 70\)              \(H_a\): \(\mu_{CALL} > 70\)

  • The reasoning goes as follows:
    • Suppose \(H_0\) is true, what is the chance \(p\) of observing a sample with \(m \geq\) 74?
    • To determine this, we convert 74 to a \(z\)-score: $z = (m - \mu) / $SE = (74-70)/2 = 2
    • And find the associated \(p\)-value (about 0.025)

Statistical reasoning (2)

\(H_0\): \(\mu_{CALL} = 70\)              \(H_a\): \(\mu_{CALL} > 70\)

  • \(P(z \geq 2) \approx 0.025\)
    • The chance of observing a sample at least this extreme given \(H_0\) is true is 0.025
    • This is the \(p\)-value (measured significance level)
    • If \(H_0\) were correct and kids with CALL exp. had the same language proficiency as others, the observed sample would be expected only 2.5% of the time
      • Strong evidence against the null hypothesis

Statistically significant?

  • We have determined \(H_0\), \(H_a\) and the \(p\)-value
  • The classical hypothesis test assesses how unlikely a sample must be for a test to count as significant
  • We compare the \(p\)-value against this threshold significance level or \(\alpha\)-level
  • If the \(p\)-value is lower than the \(\alpha\)-level (usually 0.05, but it may be lower as well), we regard the result as significant and reject the null hypothesis

Statistical significance: summary

  • The \(p\)-value is the chance of encountering the sample, given that the null hypothesis is true
  • The \(\alpha\)-level is the threshold for the \(p\)-value, below which we regard the result as significant
    • If the result is significant, we reject \(H_0\) and assume \(H_a\) is true

Question 12

Steps for assessing statistical significance

  1. Specify \(H_0\) and \(H_a\)
  2. Specify test statistic (e.g., mean) and underlying distribution (assuming \(H_0\))
  3. Specify the \(\alpha\)-level at which \(H_0\) will be rejected
  4. Determine the value of the statistic (e.g., mean) on the basis of a sample
  5. Calculate the \(p\)-value and compare to \(\alpha\)
    • \(p\)-value \(< \alpha\): reject \(H_0\) (significant result)
    • \(p\)-value \(\geq \alpha\): retain \(H_0\) (non-significant result)

Critical values

  • Critical values: those values of the sample statistic resulting in a rejection of \(H_0\)
  • E.g., if \(\alpha\) is set at 0.05, the critical region is \(P(z) < 0.05\), i.e. \(z \geq 1.64\)
  • We can transform this to raw values using the \(z\) formula \[z = (x-\mu)/SE\\ 1.64 = (x-70)/2\\ 3.3 = x-70\\ x = 73.3\]
  • Thus a sample mean of at least 73.3 will result in rejection of \(H_0\)

One-sided test

  • There are different forms of statistical tests:
    • \(H_a\) predicts high \(m\): CALL improves language ability
    • \(H_a\) predicts low \(m\): Eating broccoli lowers cholesterol levels

plot of chunk unnamed-chunk-17

Two-sided test

  • Sometimes \(H_a\) might predict not lower or higher, but just different
  • With a significance level \(\alpha\) of 0.05, both very high (2.5% highest) and very low (2.5% lowest) values give reason to reject \(H_0\)

plot of chunk unnamed-chunk-18

Statistical significance and confidence interval

  • Statistical significance and a confidence interval (CI) are linked
  • A 95% CI based on the sample mean \(m\) represents the values for \(\mu\) for which the difference between \(\mu\) and \(m\) is not significant (at the 0.05 significance threshold for a two-sided test)
    • A value outside of the CI indicates a statistically significant difference

plot of chunk unnamed-chunk-19

Chasing significance?

  • If your result is not significant, you could try to obtain more data (reducing the standard error)
  • Is it sensible to collect the extra data to "push" a result to significance?
    • No. At least, usually not.
  • The real result is the effect size (e.g., the difference between the groups)

Understanding significance

  • "Statistically significant" implies that an effect probably is not due to chance, but the effect can be very small
    • If you want to know whether you should buy CALL software to learn a language, statistically significant does not tell you this
    • This is a two-edged sword, if an effect was not statistically significant, it does not mean nothing important is going on
      • You are just not sure: it could be a chance effect

Question 13

Misuse of significance

  • Garbage in, garbage out: statistics won't help an experiment with a poor design, or where data was poorly collected
  • No significance hunting: hypotheses should be formulated before data collection and analysis
    • Modern danger: if there are many potential variables, it is likely that a few turn out to be significant
      • Specific tests are necessary to correct for this

Some remarks about hypothesis testing

  • A statistical hypothesis concerns a population (not a sample!) and involves a statistic (such as mean, frequency, etc.)
    • Population: all students attending a course using online lecture questions
    • Parameter (statistic): (average) course performance
    • Hypothesis: average performance of students answering online lecture questions is higher than those who do not

Identifying hypotheses

  • Alternative hypothesis \(H_a\) (original hypothesis) is contrasted with null hypothesis \(H_0\) (hypothesis that nothing out of the ordinary is going on)
    • \(H_a\): average performance of students answering online lecture questions higher
    • \(H_0\): answering online lecture questions does not impact performance
  • Logically \(H_0\) should imply \(\neg H_a\)

Possible errors

Of course, you could be wrong (e.g., due to an unrepresentative sample)!

\(H_0\) true false
retained correct type II error
rejected type I error correct
  • Hypothesis testing focuses on type I errors:
    • \(p\)-value: chance of type I error
    • \(\alpha\)-level: boundary of acceptable level of type I error
  • Type II errors:
    • \(\beta\): chance of type II error
    • \(1 - \beta\): power of statistical test
      • More sensitive (and useful) tests have more power to detect an effect

Possible errors: easier to remember

  • False positive: incorrect positive (accepting \(H_a\)) result
  • False negative: incorrect negative (not rejecting \(H_0\)) result

How to formulate the results?

  • Results with \(p = 0.051\) are not very different from \(p = 0.049\), but we need a boundary
    • An \(\alpha\)-level of \(0.05\) is low as the "burden of proof" is on the alternative
  • If \(p = 0.051\) we haven't proven \(H_0\), only failed to show that it's really wrong
    • This is called "retaining \(H_0\)"

Recap

  • In this lecture, we've covered
    • Descriptive vs. inferential statistics
    • Sample vs. population
    • (Types of) variables
    • Distribution of a variable: central tendency and variation
    • Standardized scores
    • Checking for a normal distribution
    • Relation between population (mean) and sample (mean)
    • Confidence interval for population mean based on sample mean
    • Testing a hypothesis about the population using a sample
    • Statistical significance
    • Error types

Evaluation

Questions?

Thank you for your attention!

http://www.martijnwieling.nl
wieling@gmail.com
